Open Cycle MIN.D.
Details
Modern road bike tech focused on long-ride comfort in a classic, minimal design.
The joy of cycling starts even before the first pedal stroke, as you collect your MIN.D., feel its lightness, admire the sleek tube profiles, see the shimmering midnight blue, smile at the splash of color from the 4 OPEN logo colors fading into each other on the inside of the fork and chainstays.
Once on the bike, a strange combination of performance and comfort becomes apparent. Every gram of material has a function. Beyond it is nothing, other than the endless draw of roads unknown.
WHAT IS THE MIN.D.?
- A high performance road bike frame using OPEN’s ultra-efficient tube shaping for power transfer, low weight & high strength
- Continuous seattube design for extreme comfort without gimmicks
- Tire clearance for modern road tires up to 32mm (since tire labelling is unreliable, always check tire clearance with the frame)
- Available in standard 2x and dedicated 1x version
- Classic, understated look in both shaping and color
Contact us to customize your bike.
Comfort is not about gimmicks, elastomers, electronic suspension or sub-atomic vibration damping graphene-infused nano-particles. It's about finding ways to ride further, for longer, while enjoying it.
A comfortable fit geometry comes first. Secondly, bad roads are one of the worst comfort killers, whether through cracks and potholes or simply through vibrations. Making your tires a tad larger is the most effective comfort boost while also improving rolling resistance and grip.
Finally, OPEN creates comfort through the frame shape and layup, in particular the seattube/seatmast and the seatstays.
The continuous seattube design is extremely small at 25mm diameter (30mm is normally the minimum if you want to fit in a 27.2mm seatpost). This change adds astonishing comfort to the frame. Removing the seatpost/seattube overlap at the toptube also means the seattube compliance continues uninterrupted.
It may sound weird that we consider this one of the most important features of the MIN.D. But as Dieter Rams said: “As little design as possible”. This is a pure road bike, and nothing more. Simply because it doesn’t have to be anything else.
OPEN has done a lot of work on steering geometry in the past five years. The MIN.D, takes everything they've learned from their road bike test mule and gravel bike on/off-road geometry experiments, putting it back into a pure road bike geometry
The OPEN U-Turn was the first fork truly optimized for flatmount brakes by deleting the standard adaptor to switch between 140mm and 160mm disc rotors (you should always use 160mm rotors anyway for added safety & control at almost no extra weight). The adaptor is a feature without a benefit at the expense of weight, stiffness and complexity.
The R-Turn uses the same Smartmount direct-mount design with thru-bolts without adaptors, just like the rear brake. Together with new shaping and a new layup optimized for road, the R-Turn is the lightest disc brake road fork available.
Note: For SRAM or Shimano, remove the adaptor and use bolts recommended for a 30mm “rear chainstay thickness”. For Campagnolo, use a “140 mm REAR" disc caliper with bolts “for 30-34 mm rear mount”.
Vertically thin chainstays and seatstays provide compliance, while their lateral width and layup ensure rock-solid propulsion. Truly the best of both worlds.
OPEN-custom seattube top clamp with micro-wedge is barely visible, just the two countersunk set screws reveal the adjustment mechanism.
Clean, simple, hassle-free, that’s why the Ritchey system is so popular. The MIN.D. comes standard with the side plates for round 7mm and 7x9.6mm oval rails.
The MIN.D, internal routing is designed for electronic groupsets from SRAM, Shimano and Campagnolo.
Lock bolt secures the hanger in the frame using the same threads that secure the thru axle on the other side. Simpler, lighter & optimized for the stiffest thru-axle: Syntace X-12.
Flatmount brake calipers attach directly onto the fork & frame, positioned for 160mm discs. No front or rear adaptors/spacers required.
